Terminal Byte Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
X333
n+6 Pin10
DI 6.7
Pin9
DI 6.6
Pin8
DI 6.5
Pin7
DI 6.4
Pin6
DI 6.3
Pin5
DI 6.2
Pin4
DI 6.1
Pin3
DI 6.0
n+7 Pin18
DI 7.7
Pin17
DI 7.6
Pin16
DI 7.5
Pin15
DI 7.4
Pin14
DI 7.3
Pin13
DI 7.2
Pin12
DI 7.1
Pin11
DI 7.0
n+8 Pin26
DI 8.7
Pin25
DI 8.6
Pin24
DI 8.5
Pin23
DI 8.4
Pin22
DI 8.3
Pin21
DI 8.2
Pin20
DI 8.1
Pin19
DI 8.0
Output image
The image comprises one slot (n ≙ start address):
Digital outputs (DO): n+0 … n+5 (6 byte)
Table 9-27 Output image of digital outputs for the 1st I/O module (n=0)
Terminal Byte Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
X111
n+0 Pin38
DO 0.7
Pin37
DO 0.6
Pin36
DO 0.5
Pin35
DO 0.4
Pin34
DO 0.3
Pin33
DO 0.2
Pin32
DO 0.1
Pin31
DO 0.0
n+1 Pin46
DO 1.7
Pin45
DO 1.6
Pin44
DO 1.5
Pin43
DO 1.4
Pin42
DO 1.3
Pin41
DO 1.2
Pin40
DO 1.1
Pin39
DO 1.0
X222
n+2 Pin38
DO 2.7
Pin37
DO 2.6
Pin36
DO 2.5
Pin35
DO 2.4
Pin34
DO 2.3
Pin33
DO 2.2
Pin32
DO 2.1
Pin31
DO 2.0
n+3 Pin46
DO 3.7
Pin45
DO 3.6
Pin44
DO 3.5
Pin43
DO 3.4
Pin42
DO 3.3
Pin41
DO 3.2
Pin40
DO 3.1
Pin39
DO 3.0
X333
n+4 Pin38
DO 4.7
Pin37
DO 4.6
Pin36
DO 4.5
Pin35
DO 4.4
Pin34
DO 4.3
Pin33
DO 4.2
Pin32
DO 4.1
Pin31
DO 4.0
n+5 Pin46
DO 5.7
Pin45
DO 5.6
Pin44
DO 5.5
Pin43
DO 5.4
Pin42
DO 5.3
Pin41
DO 5.2
Pin40
DO 5.1
Pin39
DO 5.0
9.2.4.2 Diagnostics via input image
Table 9-28 Diagnostics input image
Byte Bit7 Bit6 Bit5 Bit4 Bit3 Bit3 Bit1 Bit0
d+0 count_2 count_1 count_0 T_Alarm_2 T_Alarm_1 Diag_2 Diag_1 Diag_0
d+1 Status_1
Table 9-29 Messages in byte 0
Bit Signal name Message
7 count_2 alive and well 2
6 count_1 alive and well 1
5 count_0 alive and well 0
4 T_Alarm_2 Temperature not within the operating temperature range dened for the
module
3 T_Alarm_1 Critical temperature exceeded
