Siemens SINUMERIK 840D sl Equipment Manual

Figure 7-5 Ethernet ports
Cable speci󹪝cation
Table 7-12 Cable speci󹪝cation for X120, X130, and X127
Characteristic Version
Connector type RJ45 socket
Cable type Industrial Ethernet cable (CAT5)
Max. cable length 100 m
7.8 PROFINET
7.8.1 Application
Application
The following communication networks can be established via the PROFINET interface:
• PROFINET CBA:
Communication between controllers as components in distributed systems
• PROFINET IO
Communication between the PLC controller and 󹪝eld devices
Properties
The PROFINET interface X150 is equipped with an integrated 2-port switch and a TCP/IP address
for the 2 ports.
Pin assignment
Table 7-13 PROFINET interface, X150 ports 1, 2
Pin Signal name Signal type Meaning
1 TXP B Transmit data +
2 TXN B Transmit data -
3 RXP B Receive data +
4 - - Reserved, do not use
5 - - Reserved, do not use
6 RXN B Receive data -
7 - - Reserved, do not use
Connecting
7.8 PROFINET
NCU 7x0.3B PN
60 Equipment Manual, 10/2020, 6FC5397-1EP40-6BA1

Siemens SINUMERIK 840D sl Specifications

General

Control Type	CNC
Number of Axes	Up to 31
Max Number of Channels	10
Interfaces	Ethernet, PROFIBUS, PROFINET, USB
Interpolation	5-axis interpolation
Operating Temperature	0°C to 45°C
Relative Humidity	Up to 95% (non-condensing)
Display	TFT color display, various sizes
Programming Languages	DIN/ISO
Safety Features	Safety Integrated
PLC	Integrated PLC S7-300
Drive Interface	SINAMICS S120
Data Storage	CF card, USB
Operating System	Windows-based
