Siemens SINUMERIK 840D sl Equipment Manual

Appendix
A
A.1 Documentation overview SINUMERIK 840D sl
You will 󹪝nd extensive documentation on the functions of SINUMERIK 840D sl from version 4.8
SP4 at 840D sl documentation overview (
https://support.industry.siemens.com/cs/ww/en/view/
109766213).
You can display the documents or download them in PDF or HTML5 format.
The documentation is divided into the following categories:
• User: Operating
• User: Programming
• Manufacturer/Service: Functions
• Manufacturer/Service: Hardware
• Manufacturer/Service: Con󹪝guration/Setup
• Manufacturer/Service: Safety Integrated
• Manufacturer/Service: SINUMERIK Integrate/MindApp
• Information and training
• Manufacturer/Service: SINAMICS
A.2 Abbreviations
AWG American Wire Gauge
B-MPI Handheld unit with MPI connection
BERO Proximity limit switch
CAT5 Quality class (category) for shielded twisted-pair cables. Class 5 states that these cables have a particularly low
damping factor, making them suitable for 100 Mbit/s-FastEthernet networks.
NCU 7x0.3B PN
Equipment Manual, 10/2020, 6FC5397-1EP40-6BA1 159

Siemens SINUMERIK 840D sl Specifications

General

Control Type	CNC
Number of Axes	Up to 31
Max Number of Channels	10
Interfaces	Ethernet, PROFIBUS, PROFINET, USB
Interpolation	5-axis interpolation
Operating Temperature	0°C to 45°C
Relative Humidity	Up to 95% (non-condensing)
Display	TFT color display, various sizes
Programming Languages	DIN/ISO
Safety Features	Safety Integrated
PLC	Integrated PLC S7-300
Drive Interface	SINAMICS S120
Data Storage	CF card, USB
Operating System	Windows-based
