9.3.2 Dimension drawing










 
Figure 9-15 PP 72/48D 2/2A PN dimension drawing
9.3.3 Mounting
The PP 72/48D 2/2A PN I/O module is mounted just the same as the PP 72/48D PN, see Mounting
(Page 102).
Connectable components
9.3 PP 72/48D 2/2A PN
NCU 7x0.3B PN
Equipment Manual, 10/2020, 6FC5397-1EP40-6BA1 121
