7.7 Use of Ethernet interfaces
Application
The following connections can be established via the Ethernet interfaces:
• X120 provides the link to the system network (e.g. operator panels).
• X130 connects the NCU to the company network.
• X127 is used for commissioning and remote diagnostics via teleservice adapter IE.
You can nd further details in the following manuals:
– SINUMERIK 840D sl Basesoftware and Operating Software Commissioning Manual
– SIMATIC TS Adapter IE Manual
Properties
The interfaces are full duplex 10/100/1000 Mbit Ethernet ports. Both ports are connected as an
Ethernet terminal.
Pin assignment
Table 7-9 Ethernet interfaces X120, X130, X127 in the 10/100 Mbit mode
Pin Signal name Signal type Meaning
1 TXP B Transmit data +
2 TXN B Transmit data -
3 RXP B Receive data +
4 - - Reserved, do not use
5 - - Reserved, do not use
6 RXN B Receive data -
7 - - Reserved, do not use
8 - - Reserved, do not use
Signal type: B = bidirectional
Table 7-10 Ethernet interfaces X120, X130, X127 in the 1 Gbit mode
Pin Signal name Signal type Meaning
1 DA+ B Bidirectional pair A+
2 DA- B Bidirectional pair A-
3 DB+ B Bidirectional pair B+
4 DC+ B Bidirectional pair C+
5 DC- B Bidirectional pair C-
6 DB- B Bidirectional pair B-
7 DD+ B Bidirectional pair D+
Connecting
7.7 Use of Ethernet interfaces
NCU 7x0.3B PN
58 Equipment Manual, 10/2020, 6FC5397-1EP40-6BA1
