6.12 System settings for power up, RESET and part program start
6-178
 Siemens AG 2000 All Rights Reserved
SINUMERIK 840D Installation and Start-Up Guide (IAD) – 04.00 Edition
S RESET / part program end
MD 20110: RESET_MODE_MASK, bit 4–10 = 0 or 1
Bits 4 to 10 can be combined in any way.
RESET/
part program end
MD 20110
RESET_MODE_MASK
bit 0
bit 0=0
bit 0=1
The current settings are retained.
The following initial setting is activated on
the next part program start:
– G codes acc. to MD 20150: GCODE_
RESET_VALUES
– Tool length compensation not active
– Transformation not active
– No coupled-axis groupings active
– No tangential correction active
Depending on how they are set bits 4 to 10 affect:
– Current plane
– Frame currently set
– Active tool offset
– Active transformation
– Coupled-axis groupings
– Tangential correction
– Unconfigured synchronous spindle coupling
If synchronous spindle coupling is configured, the coupling is
set depending on MD 21330: COUPLE_RESET_MODE_1.
Fig. 6-46 System settings after RESET/part program end
