Page #87 background imageLoading...
Page #87 background image
6 Assi
g
nin
g
Parameters to the Control and the PLC Pro
g
ram
6
03.96
6.1 Machine and setting data
6-87
 Siemens AG 2000 All Rights Reserved
SINUMERIK 840D Installation and Start-Up Guide (IAD) – 04.00 Edition
6.1 Machine and setting data
The control system is adapted to the machine by means of machine and setting
data.
The machine data (MD) are classified as follows:
S General machine data
S Channel-specific machine data
S Axis-specific machine data
S Machine data for operator panel
S Machine data for feed drive
S Machine data for main spindle drive
The setting data (SD) are classified as follows:
S General setting data
S Channel-specific setting data
S Axis-specific setting data
For enabling options. The option data are included in the scope of delivery of
the option concerned.
The machine and setting data are classified as follows:
Table 6-1 Overview of machine and setting data
Area Designation
from 1000 to 1799 Machine data for drives
from 9000 to 9999 Machine data for operator panel
from 10000 to 18999 General machine data
from 19000 to 19999 Reserved
from 20000 to 28999 Channel-specific machine data
from 29000 to 29999 Reserved
from 30000 to 38999 Axis-specific machine data
from 39000 to 39999 Reserved
from 41000 to 41999 General setting data
from 42000 to 42999 Channel-specific data
from 43000 to 43999 Axis-specific setting data
from 51000 to 61999 General machine data for compile cycles
from 62000 to 62999 Channel-specific machine data for compile cycles
from 63000 to 63999 Axis-specific machine data for compile cycles
References: /LIS/, Lists
Parameterization
Machine data
Setting data
Option data
Overview of
machine and
setting data
