8
03.96
8.1 Alarm and message texts
8-192
Siemens AG 2000 All Rights Reserved
SINUMERIK 840D Installation and Start-Up Guide (IAD) – 04.00 Edition
8.1.4 Syntax for alarm text files
The following alarm numbers are available for alarms relating to cycles, compile
cycles and the PLC:
Table 8-1 Alarm numbers for cycle, compile cycle and PLC alarms
Number range Designation Effect Clear
60000 – 60999 Cycle alarms
Display, NC start disable Reset
61000 – 61999
(Siemens)
Display, NC start disable,
axis/spindle standstill
Reset
62000 – 62999 Display Cancel
63000 – 64999 Reserved
65000 – 65999 Cycle alarms
Display, NC start disable Reset
66000 – 66999
(user)
Display, NC start disable,
axis/spindle standstill
Reset
67000 – 67999 Display Cancel
68000 – 69000 Reserved
70000 – 79999 Compile cycle alarms
400000 – 499999 PLC alarms, general
500000 – 599999 PLC alarms for channel
600000 – 699999 PLC alarms for axis and
spindle
700000 – 799999 PLC alarms for user
800000 – 899999 PLC alarms for sequential
controllers/graphs
The number range in the list is not available with every number
(see References: /FB/ P3, “PLC basic program”, Lists)
The structure of the text file for cycle and compile cycle alarms is as follows:
Table 8-2 Structure of text file for cycle alarm texts
Alarm number Display Help ID Text or alarm number
60100 10“No D number %1 programmed”
60101 1 0 60100
... ... ... ...
65202 01“Axis %2 in channel %1 is still moving”
// Alarm text file for cycles in German
Alarm number list
Alarm numbers
Text file
format for
cycle alarm texts
Alarm number
8 Alarm and Messa
e Texts
07.98
