3
03.96
3.5 Handheld programming unit
3-57
 Siemens AG 2000 All Rights Reserved
SINUMERIK 840D Installation and Start-Up Guide (IAD) – 04.00 Edition
Example: Display on the HPU
Waiting for PLC
V04.01.01 B
→ Software version of the HPU is V4.11
→ Bus address of the HPU is B
hex
(11)
3.5.1 Interface signals of the HPU
The MCP simulation is available for the HPU. The MCP simulation of the HPU
must be parameterized as an MCP in function block FB1 so that the PLC basic
program can monitor the failure of the HPU.
The parameter setting for the start address n is set in the PLC user program
(FB1).
Table 3-6 Interface HPU –> PLC
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
IBn REF TEACH AUTO MDA JOG QUIT RESET WCS/MCS
IBn+1 Reserved U4 U3 Shift key U2 U1 INC REPOS
JOG keys positive direction
IBn+2 Reserved Reserved C/6 B/5 A/4 Z/3 Y/2 X/1
JOG keys negative direction
IBn+3 Reserved Reserved C/6 B/5 A/4 Z/3 Y/2 X/1
IBn+4 Signal Diagno Service System Param Correct Program Machine
IBn+5 F5 F4 F3 F2 1F Step Modify Insert
IBn+6 Reserved Reserved + – S2 S1 START STOP
IBn+7 Reserved
Note:
– Only keys displayed against a gray background are evaluated by the basic PLC program (FC26).
– Keys U1 to U4 and F1 to F5 or their inputs may be freely assigned by the PLC user.
FC 26 also exists and is analogous with PLC functions FC 19 and FC 25. It is
described in
Reference: /FB/P3, Basic PLC Program
Input signals
3 Settin
s, MPI / OPI
08.9712.97
