Siemens SINUMERIK 840D Installation And Startup Guide

10
03.96
10.10 Automatic controller setting (only MMC 103, SW 4.3 and higher)
10-243
 Siemens AG 2000 All Rights Reserved
SINUMERIK 840D Installation and Start-Up Guide (IAD) – 04.00 Edition
Bandwidth:
Any of the available bandwidths can be selected in order to test the automatic
controller setting.
Averaging:
Influences the quality of the measurement.
Offset:
Input of load velocity in mm/min (should be greater than the amplitude by a
factor of at least 2).
J
10 Drive Optimization with Start-Up Tool
05.9805.98

Siemens SINUMERIK 840D Specifications

General

Series	SINUMERIK 840D
Axes	Up to 31
Channels	Up to 10
Operating System	Windows-based
Power Supply	24 V DC
Control Unit Type	CNC
Interface	Ethernet, PROFIBUS
Display	TFT color display
Interpolation	Spline
PLC	Integrated PLC
Data Storage	CompactFlash, USB
