11
03.96
11.3 Data backup via MMC 102/103
11-261
Siemens AG 2000 All Rights Reserved
SINUMERIK 840D Installation and Start-Up Guide (IAD) 04.00 Edition
Position the cursor on the initialization program (INI) directory. Press the V24
softkey. The initialization program %_N_INITIAL_INI is output with the follow-
ing data:
S Global user data
S Option data
S Protection zones
S R parameters
S Setting data
S Machine data
S Tool/magazine data
S Zero offsets
None
Compensation data (EEC, QEC, CEC)
Part programs
Definition data and macros
Part programs, workpieces, cycles
PLC programs and data
Display machine data, drive machine data
If you position the cursor on NC active data and initiate the data output via
V.24, an initialization program %_N_INITIAL_INI is also output, but with all data
stored in the NC active data directory. That is including compensation data.
Output of
initialization
program (INI)
11 Data Backup
