Siemens SINUMERIK 840D Installation And Startup Guide

2
03.96
2.2 Electrical configuration
2-33
 Siemens AG 2000 All Rights Reserved
SINUMERIK 840D Installation and Start-Up Guide (IAD) – 04.00 Edition
S MMC 101/102
S ISA adapter
S Link interface
S Digitizing module
S NCU 572/573 for digitizing
S Connecting cable from digitizing module to link interface
S Tactile probe (e.g. Renishaw SP2–1) with cable
For further information, please refer to the following documentation:
References: /FBD/Description of Functions, Digitizing
J
Hardware
requirements for
digitizing
2 Confi
g
uration

Siemens SINUMERIK 840D Specifications

General

Series	SINUMERIK 840D
Axes	Up to 31
Channels	Up to 10
Operating System	Windows-based
Power Supply	24 V DC
Control Unit Type	CNC
Interface	Ethernet, PROFIBUS
Display	TFT color display
Interpolation	Spline
PLC	Integrated PLC
Data Storage	CompactFlash, USB
