3
03.96
3.5 Handheld programming unit
3-60
Siemens AG 2000 All Rights Reserved
SINUMERIK 840D Installation and Start-Up Guide (IAD) – 04.00 Edition
Note
For a description of the “Global data” menu and its applications, please refer to
References: /S7HT/ SIMATIC Step7 Manual, Start-up of MPI
Bus Nodes
A network must be activated via the configuration for every CPU program. Since
there is no separate order number for the MCP/HHU CPU programs, the stan-
dard order number of the AS314 must be used.
CPU program MPI address
AS314 2
MCP
6
HHU 15
HPU 11
“0” must always be entered as the MPI SUB network number.
“Networking” sequence for each CPU program:
1. Set “Module networked”.
2. Set MPI address and enter SUB network no. 0.
3. Confirm with OK softkey
4. Save the configuration with Save softkey
The SDB supplied in the basic PLC program is valid for the first MCP or the
HPU and must be reconfigured as required.
Networking
SDB
3 Settin
s, MPI / OPI
08.97
