① Switch S1
② LEDs H1 ... H6
③ X111 Digital input/outputs 1
④ X222 Digital input/outputs 2
⑤ X333 Digital input/outputs 3
⑥ Grounding screw
⑦ Shield contact
⑧ X3 Analog inputs/outputs
⑨ X2, port 1 PROFINET interface
⑩ X1 Power supply connection
⑪ X2, port 1 PROFINET interface
Figure12-8 PP 72/48D 2/2A PN I/O module
Note
The type plate is located on the rear side of the mounting plate. Note the relevant data because
the type plate is no longer visible after installation.
Connectable components
12.2PP 72/48D PN and PP 72/48D 2/2A PN
NCU 1750
114 Equipment Manual, 10/2023, A5E45627807B AH
