Correcting errors at counter value "2"
Value
of
byte1
Cause E󹪜ect Remedy
1 In the temperature measure‐
ment operating mode, an in‐
put voltage is too high. The
hardware may become dam‐
aged/destroyed as a result.
The "PNFault" LED is activated.
The outputs are switched
o󹪜.
1)
The value 0x80 is stored in
status byte 1.
It is essential that a Pt100 el‐
ement is connected to termi‐
nals 3-4 or 7-8.
The module must be restar‐
ted with Power ON following
elimination of the error.
2 Reserved - -
3 Overload at the outputs The "PNFault" LED is activated.
The outputs are switched
o󹪜.
1)
The value 0x80 is stored in
status byte 1.
Check the loads at the analog
output.
The module must be restar‐
ted with Power ON following
elimination of the error.
4 Incorrect operating mode se‐
lection, e.g. temperature
measurement at the analog
outputs.
Selection of the operating
mode is rejected.
If selected correctly, the mod‐
ule switches to cyclic opera‐
tion.
5 Internal error, system error The "PNFault" LED is activated.
The outputs are switched
o󹪜.
1)
The value 0x80 is stored in
status byte 1.
The 󹪝rmware has detected a
system error, this status can
only be exited by means of a
switch-on / switch-o󹪜.
6 Overrange at the inputs Check input circuit and ad‐
just, if required.
7 Overrange at the outputs Correct the values in the user
program.
1)
The analog outputs retain their last output value.
12.2.5 Technical data
Table 12-35 Technical data of the I/O module
PP 72/48D PN PP 72/48D 2/2A PN
Safety
Degree of protection IP 00 according to EN 60529
Overvoltage category OVC II
Protection class III; DVC A, (PELV) acc. to EN 61800-5-1
Approvals CE, cULus, KCC, EAC
Electrical data
Input voltage 24 VDC + 20%/- 15%
Rated current 0.7A 0.8 A
Power consumption at rated load
(without digital outputs)
17 W 19 W
Connectable components
12.2PP 72/48D PN and PP 72/48D 2/2A PN
NCU 1750
142 Equipment Manual, 10/2023, A5E45627807B AH
