8.10 Digital inputs/outputs
8.10.1 DIO application
Connecting sensors and actuators
Digital inputs and outputs can be used to connect various sensors and actuators to the 14-pin
connectors X122 / X132 / X142 on the front panel. The interfaces are permanently assigned:
• X122 and X132: Drive
• X142: Control.
The following types of digital I/O are used:
• Digital inputs (isolated)
• Digital outputs
• Bidirectional digital inputs/outputs (only for drive terminals)
The assignment of I/Os to functions can be parameterized freely by the user. Special
functions, such as probe inputs (rapid inputs only) and cam outputs, can also be assigned to
the inputs/outputs.
The enables for the drive units and/or motors (Line Module, Motor Module) connected to the
NCU can be switched using the digital inputs.
Note
Terminal assignments
When commissioning the drive wizard, the digital inputs/outputs are correspondingly
preassigned functions.
For more information about terminal assignment, see:
• System Manual Guidelines for the Machine Con󹪝guration
Access to digital inputs/outputs
Note
The digital inputs/outputs of the drive terminals are updated in accordance with the set
PROFIBUS bus clock cycle of SINAMICS Integrated.
Connecting
8.10Digital inputs/outputs
NCU 1750
82 Equipment Manual, 10/2023, A5E45627807B AH
