Siemens SINUMERIK ONE 6FC5317-5AA00-0AA0 User Manual

12.2.3 Connecting
12.2.3.1 Interface overview
3RZHUVXSSO\
7HUPLQDOVWULSFRQYHUWHU
5LEERQFDEOH
352),1(7FDEOH
'LJLWDO,2
3RUWVDQG
33'31
9'&
352),1(7;
;
;
;
;
1&8[
6,180(5,.21(0&3
Figure12-12 I/O module connection options
Table 12-12 PP 72/48D PN I/O module interfaces
Interface Designation Type
Power supply connection X1 Screw-type terminal block
PROFINET IO X2 (ports 1 and 2) Socket
PROFINET address S1 DIP switch
Digital input/outputs 1 X111 Ribbon cable connector
Digital input/outputs 2 X222 Ribbon cable connector
Digital input/outputs 3 X333 Ribbon cable connector
Connectable components
12.2PP 72/48D PN and PP 72/48D 2/2A PN
NCU 1750
Equipment Manual, 10/2023, A5E45627807B AH 119
