3RZHUVXSSO\
3RZHUVXSSO\
7HUPLQDOVWULSFRQYHUWHU
5LEERQFDEOH
&RQQHFWLRQFDEOHPD[LPXPb
P
);'&
'LJLWDO,2
$QDORJ,2
3RUWVDQG
33'$31
9'&
352),1(7;
;
;
;
;
;
1&8[
6,180(5,.21(0&3
Figure12-13 Connection options of the PP 72/48D 2/2A PN I/O module
Table 12-13 Interfaces of the PP 72/48D 2/2A PN I/O module
Interface Designation Type
Power supply connection X1 Screw-type terminal block
PROFINET IO X2 (ports 1 and 2) Socket
Analog inputs/outputs X3 Terminal block
PROFINET address S1 DIP switch
Digital input/outputs 1 X111 Ribbon cable connector
Digital input/outputs 2 X222 Ribbon cable connector
Digital input/outputs 3 X333 Ribbon cable connector
The following abbreviations are used:
Signal type Meaning
I Input
O Output
B Bidirectional
V Supply voltage
GND Protective ground (reference potential)
Note
Digital and analog signals must not be laid together within a cable.
Connectable components
12.2PP 72/48D PN and PP 72/48D 2/2A PN
NCU 1750
120 Equipment Manual, 10/2023, A5E45627807B AH
