Pin Signal name Type Pin Signal name Type
17 Input 4.6 I 18 Input 4.7 I
19 Input 5.0 I 20 Input 5.1 I
21 Input 5.2 I 22 Input 5.3 I
23 Input 5.4 I 24 Input 5.5 I
25 Input 5.6 I 26 Input 5.7 I
27 Not assigned - 28 Not assigned -
29 Not assigned - 30 Not assigned -
31 Output 2.0 O 32 Output 2.1 O
33 Output 2.2 O 34 Output 2.3 O
35 Output 2.4 O 36 Output 2.5 O
37 Output 2.6 O 38 Output 2.7 O
39 Output 3.0 O 40 Output 3.1 O
41 Output 3.2 O 42 Output 3.3 O
43 Output 3.4 O 44 Output 3.5 O
45 Output 3.6 O 46 Output 3.7 O
47 DOCOM2 VI 48 DOCOM2 VI
49 DOCOM2 VI 50 DOCOM2 VI
VI: Voltage input / VO: Voltage output
I: Signal input / O: Signal output / GND: Reference potential (ground)
Table 12-25 Pin assignment for X333
Pin Signal name Type Pin Signal name Type
1 M GND 2 P24OUT VO
3 Input 6.0 I 4 Input 6.1 I
5 Input 6.2 I 6 Input 6.3 I
7 Input 6.4 I 8 Input 6.5 I
9 Input 6.6 I 10 Input 6.7 I
11 Input 7.0 I 12 Input 7.1 I
13 Input 7.2 I 14 Input 7.3 I
15 Input 7.4 I 16 Input 7.5 I
17 Input 7.6 I 18 Input 7.7 I
19 Input 8.0 I 20 Input 8.1 I
21 Input 8.2 I 22 Input 8.3 I
23 Input 8.4 I 24 Input 8.5 I
25 Input 8.6 I 26 Input 8.7 I
27 Not assigned - 28 Not assigned -
29 Not assigned - 30 Not assigned -
31 Output 4.0 O 32 Output 4.1 O
33 Output 4.2 O 34 Output 4.3 O
35 Output 4.4 O 36 Output 4.5 O
37 Output 4.6 O 38 Output 4.7 O
Connectable components
12.2PP 72/48D PN and PP 72/48D 2/2A PN
