Front nameplate
You can 󹪝nd this nameplate below the service 󹪞ap for the operating and display elements. The
QR code contains information about the MLFB, FID and the MAC address of X120.
A
FS:
6FC5317-5AA00-0AA1
T-R66185017
A5E50733674
X
① QR code
Figure4-2 Nameplate (at the front)
MAC addresses
The SINUMERIK ONE NCU 1750 has 3 PROFINET interfaces. Each of the PROFINET interfaces has
a MAC address. The number range of MAC addresses is consecutive. The following table shows
how the MAC addresses are assigned:
 Assignment Lateral nameplate Front nameplate Plate on lower cover
󹪞ap
MAC addr. 1 Ethernet interface
X120
QR code with the MAC
address
MAC address labeled
QR code with the MAC
address
MAC address labeled
MAC addr. 2 Ethernet interface
X130
MAC address labeled  MAC address labeled
MAC addr. 3 Ethernet interface
X127
MAC address labeled  MAC address labeled
MAC addr. 4 Pro󹪝net interface X160 MAC address labeled  MAC address labeled
MAC addr. 5 Port X160 P1   
MAC addr. 6 Pro󹪝net interface X150 MAC address labeled  MAC address labeled
MAC addr. 7 Port X150 P1R   
MAC addr. 8 Port X150 P2R   
A nameplate for the MAC addresses of the PROFINET and Ethernet interfaces is fastened
inside the service cover of the NCU:
