Position of the power supply interface
① Power supply connectors
② Jumper
③ Functional grounding, at the housing with M5 screw Torx / 3 Nm
Note
Tighten the power supply terminal strip using a slot screwdriver.
Connecting
8.5Power supply
NCU 1750
Equipment Manual, 10/2023, A5E45627807B AH 67
