Mounting and Commissioning
3.1 Mounting and Connections
SIPROTEC, 7SJ62/64, Manual
C53000-G1140-C207-2, Release date 01.2008
404
Power Supply
Table 3-2 Jumper settings for the nominal voltage of the integrated power supply on the processor board
A–CPU to 7SJ62.../DD
Pickup Voltages of BI1 to BI3
Table 3-3 Jumper settings for the pickup voltages of the binary inputs BI1 to BI3 on the processor board
A–CPU to 7SJ62.../DD
1)
Factory settings for devices with power supply voltages of 24 VDC to 125 VDC
2)
Factory settings for devices with power supply voltages of 110 VDC to 220 VDC and 115/230 VAC
Jumper Rated Voltage
60 to 125 VDC 110 to 250 VDC
115 VAC
24/48 VDC 230 VAC
X51 1-2 2-3
Jumpers X51 to X53 are not usedX52 1-2 and 3-4 2-3
X53 1-2 2-3
interchangeable cannot be changed
Binary Inputs Jumper 19 VDC Pickup
1)
88 VDC Pickup
2)
BI1 X21 L H
BI2 X22 L H
BI3 X23 L H
