Mounting and Commissioning
3.1 Mounting and Connections
SIPROTEC, 7SJ62/64, Manual
C53000-G1140-C207-2, Release date 01.2008
405
Processor Board A–CPU for 7SJ62.../EE
Figure 3-9 Processor printed circuit board A–CPU for devices releases ../EE and higher with jumpers settings required
for the module configuration (up to firmware V4.6)
The preset nominal voltage of the integrated power supply is checked according to Table 3-4, the pickup volt-
ages of the binary inputs BI1 to BI3 are checked according to Table 3-5, and the contact mode of the binary
outputs (BO1 and BO2) is checked according to Table 3-6.
