Mounting and Commissioning
3.1 Mounting and Connections
SIPROTEC, 7SJ62/64, Manual
C53000-G1140-C207-2, Release date 01.2008
406
Power Supply
Table 3-4 Jumper settings for the nominal voltage of the integrated power supply on the processor board
A–CPU to 7SJ62.../EE
Pickup Voltages of BI1 to BI3
Table 3-5 Jumper settings for the pickup voltages of the binary inputs BI1 to BI3 on the processor printed
circuit board A–CPU for 7SJ62.../EE
1)
Factory settings for devices with power supply voltages of 24 VDC to 125 VDC
2)
Factory settings for devices with power supply voltages of 110 VDC to 220 VDC and 115/230 VAC
Contact Mode for Binary Outputs BO1 and BO2
Table 3-6 Jumper settings for the contact mode of the binary inputs BI1 to BI3 on the processor printed
circuit board A–CPU for 7SJ62.../EE
Jumper Nominal Voltage
24/48 VDC 60 to 125 VDC 110 to 250 VDC
115 to 230 VAC
X51 Not used 1-2 2-3
X52 Not used 1-2 and 3-4 2-3
X53 Not used 1-2 2-3
cannot be changed interchangeable
Binary Inputs Jumper 19 VDC Pickup
1)
88 VDC Pickup
2)
BI1 X21 L H
BI2 X22 L H
BI3 X23 L H
for Jumper Open in quiescent state
(NO)
Closed in quiescent state
(NC)
Presetting
BO1 X41 1-2 2-3 1-2
BO2 X42 1-2 2-3 1-2
