Mounting and Commissioning
3.1 Mounting and Connections
SIPROTEC, 7SJ62/64, Manual
C53000-G1140-C207-2, Release date 01.2008
420
Pickup Voltages of BI8 to BI20 for 7SJ642*-
Table 3-20 Jumper settings for the pickup voltages of the binary inputs BI8 to BI20 on the B–I/O-2 board
for model 7SJ642*-... (housing size
1
/
2
)
1)
Factory settings for devices with power supply voltages of 24 VDC to 125 VDC
2)
Factory settings for devices with power supply voltages of 110 to 220 VDC and 115 VAC or 115 to 230 VAC
Pickup Voltages of BI8 to BI33 for 7SJ645*-
Table 3-21 Jumper settings for the pickup voltages of the binary inputs BI8 to BI33 on the B–I/O-2 board
for model 7SJ645*-... (housing size
1
/
1
)
1)
Factory settings for devices with power supply voltages of 24 VDC to 125 VDC
2)
Factory settings for devices with power supply voltages of 110 to 220 VDC and 115 VAC or 115 to 230 VAC
Binary Inputs Jumper 19 VDC Pickup
1)
88 VDC Pickup
2)
Slot 19
BI8 X21 1-2 2-3
BI9 X22 1-2 2-3
BI10 X23 1-2 2-3
BI 11 X24 1-2 2-3
BI12 X25 1-2 2-3
BI13 X26 1-2 2-3
BI14 X27 1-2 2-3
BI15 X28 1-2 2-3
BI16 X29 1-2 2-3
BI17 X30 1-2 2-3
BI18 X31 1-2 2-3
BI19 X32 1-2 2-3
BI20 X33 1-2 2-3
Binary Inputs Jumper 19 VDC Pickup
1)
88 VDC Pickup
2)
Slot 33 left side Slot 19 right side
BI8 BI21 X21 1-2 2-3
BI9 BI22 X22 1-2 2-3
BI10 BI23 X23 1-2 2-3
BI11 BI24 X24 1-2 2-3
BI12 BI25 X25 1-2 2-3
BI13 BI26 X26 1-2 2-3
BI14 BI27 X27 1-2 2-3
BI15 BI28 X28 1-2 2-3
BI16 BI29 X29 1-2 2-3
BI17 BI30 X30 1-2 2-3
BI18 BI31 X31 1-2 2-3
BI19 BI32 X32 1-2 2-3
BI20 BI33 X33 1-2 2-3
