Siemens SIPROTEC 7UT63 series User Manual

2.1 General
101
7UT613/63x Manual
C53000-G1176-C160-2
2.1.6.3 Information List
1136 PoleOpenCurr I6 1A 0.04 .. 1.00 A 0.04 A Pole Open Current
Threshold End 6
5A 0.20 .. 5.00 A 0.20 A
0.1A 0.004 .. 0.100 A 0.004 A
1137 PoleOpenCurr I7 1A 0.04 .. 1.00 A 0.04 A Pole Open Current
Threshold End 7
5A 0.20 .. 5.00 A 0.20 A
0.1A 0.004 .. 0.100 A 0.004 A
1138 PoleOpenCurr I8 1A 0.04 .. 1.00 A 0.04 A Pole Open Current
Threshold End 8
5A 0.20 .. 5.00 A 0.20 A
0.1A 0.004 .. 0.100 A 0.004 A
1139 PoleOpenCurr I9 1A 0.04 .. 1.00 A 0.04 A Pole Open Current
Threshold End 9
5A 0.20 .. 5.00 A 0.20 A
0.1A 0.004 .. 0.100 A 0.004 A
1140 PoleOpenCurrI10 1A 0.04 .. 1.00 A 0.04 A Pole Open Current
Threshold End 10
5A 0.20 .. 5.00 A 0.20 A
0.1A 0.004 .. 0.100 A 0.004 A
1141 PoleOpenCurrI11 1A 0.04 .. 1.00 A 0.04 A Pole Open Current
Threshold End 11
5A 0.20 .. 5.00 A 0.20 A
0.1A 0.004 .. 0.100 A 0.004 A
1142 PoleOpenCurrI12 1A 0.04 .. 1.00 A 0.04 A Pole Open Current
Threshold End 12
5A 0.20 .. 5.00 A 0.20 A
0.1A 0.004 .. 0.100 A 0.004 A
1151 PoleOpenCurrIX1 1A 0.04 .. 1.00 A 0.04 A Pole Open Current
Threshold AuxiliaryCT1
5A 0.20 .. 5.00 A 0.20 A
1152 PoleOpenCurrIX2 1A 0.04 .. 1.00 A 0.04 A Pole Open Current
Threshold AuxiliaryCT2
5A 0.20 .. 5.00 A 0.20 A
1153 PoleOpenCurrIX3 1A 0.04 .. 1.00 A 0.04 A Pole Open Current
Threshold AuxiliaryCT3
5A 0.20 .. 5.00 A 0.20 A
1154 PoleOpenCurrIX4 1A 0.04 .. 1.00 A 0.04 A Pole Open Current
Threshold AuxiliaryCT4
5A 0.20 .. 5.00 A 0.20 A
No. Information Type of In-
formation
Comments
- >QuitG-TRP IntSP >Quitt Lock Out: General Trip
- G-TRP Quit IntSP Lock Out: General TRIP
126 ProtON/OFF IntSP Protection ON/OFF (via system port)
236.2127 BLK. Flex.Fct. IntSP BLOCK Flexible Function
301 Pow.Sys.Flt. OUT Power System fault
302 Fault Event OUT Fault Event
Addr. Parameter C Setting Options Default Setting Comments
