2 Functions

7UT613/63x Manual

C53000-G1176-C160-2

2.1.4.6 Information List

2.1.5 Setting Groups

Four independent groups of parameters can be set for the device functions. During op-

eration, you may switch between setting groups locally, via binary inputs (if so config-

ured), via the operator or service interface using a personal computer, or via the

system interface.

2.1.5.1 Setting Groups

Purpose of Setting

Groups

A setting group includes the setting values for all functions that have been selected as

Enabled during configuration of the functional scope. In the 7UT613/63x device, four

independent setting groups (Group A to Group D) are available. Whereas setting

values and options may vary, the selected scope of functions is the same for all

groups.

Setting groups enable the user to save the corresponding settings for each applica-

tion. Settings may be loaded quickly. While all setting groups are stored in the relay,

only one setting group may be active at a given time. If multiple setting groups are not

required, Group Group A is the default selection.

If the changeover option is desired, group changeover must be set to Grp Chge

OPTION = Enabled during configuration of the functional scope (address 103). For

the setting of the function parameters, each of the required 4 setting groups Group A

to Group D must be configured.

836 SwitchgCBaux M1 (Setting options depend

on configuration)
