rion, the feedback information of the assigned breaker must inform the device about
the breaker position.
The time overcurrent protection for earth current allows the breaker criterion only if an
unequivocal relationship exists between its assigned side or measuring location and
the feedback information of the breaker (SwitchgCBaux S1, SwitchgCBaux S2 to
SwitchgCBaux M5, addresses 831 to 840).
Timers There are no specific procedures on how to set the delay times CB Open Timeat ad-
dresses1711), Active Time (address 1712) and Stop Time (address 1713).
These time delays must be based on the specific loading characteristics of the equip-
ment being protected, and should be set to allow short-term overloads associated with
dynamic cold load conditions.
Cold Load Pickup
Values
The dynamic pickup values and time delays associated with the time overcurrent
stages are set in the related addresses of the stages themselves.
2.6.3 Settings
Addr. Parameter Setting Options Default Setting Comments
1701 COLDLOAD PICKUP OFF
ON
OFF Cold-Load-Pickup Function
1702 Start CLP Phase No Current
Breaker Contact
No Current Start Condition CLP for O/C Phase
1703 Start CLP 3I0 No Current
Breaker Contact
No Current Start Condition CLP for O/C 3I0
1704 Start CLP Earth No Current
Breaker Contact
No Current Start Condition CLP for O/C Earth
1705 Start CLP Ph 2 No Current
Breaker Contact
No Current Start Condition CLP for O/C Phase 2
1706 Start CLP Ph 3 No Current
Breaker Contact
No Current Start Condition CLP for O/C Phase 3
1707 Start CLP 3I0 2 No Current
Breaker Contact
No Current Start Condition CLP for O/C 3I0 2
1708 Start CLP 3I0 3 No Current
Breaker Contact
No Current Start Condition CLP for O/C 3I0 3
1709 Start CLP E 2 No Current
Breaker Contact
No Current Start Condition CLP for O/C Earth 2
1711 CB Open Time 0 .. 21600 sec 3600 sec Circuit Breaker OPEN Time
1712 Active Time 1 .. 21600 sec 3600 sec Active Time
1713 Stop Time 1 .. 600 sec; ∞ 600 sec Stop Time
