2.1 General
45
7UT613/63x Manual
C53000-G1176-C160-2
2.1.4 Power System Data 1
2.1.4.1 Topology of the Protected Object
Measured Value
Inputs
The devices of the 7UT613/63x family comprise various types with different function
facilities and different hardware scope which latter determines the number of available
analog inputs. Dependent on the ordering type, the following analog inputs are provid-
ed:
Table 2-1 Analog measuring inputs
1)
also applicable for single-phase power transformers
2)
selectable, contained in the number of 1-phase inputs
156 FREQUENCY Prot. Disabled
Enabled
Disabled Over / Underfrequency Protection
170 BREAKER FAILURE Disabled
Enabled
Disabled Breaker Failure Protection
171 BREAKER FAIL. 2 Disabled
Enabled
Disabled Breaker Failure Protection 2
180 DISCON.MEAS.LOC Disabled
Enabled
Disabled Disconnect measurment location
181 M.V. SUPERV Disabled
Enabled
Enabled Measured Values Supervision
182 Trip Cir. Sup. Disabled
2 Binary Inputs
1 Binary Input
Disabled Trip Circuit Supervision
186 EXT. TRIP 1 Disabled
Enabled
Disabled External Trip Function 1
187 EXT. TRIP 2 Disabled
Enabled
Disabled External Trip Function 2
190 RTD-BOX INPUT Disabled
Port C
Port D
Disabled External Temperature Input
191 RTD CONNECTION 6 RTD simplex
6 RTD HDX
12 RTD HDX
6 RTD simplex Ext. Temperature Input Connec-
tion Type
Addr. Parameter Setting Options Default Setting Comments
Type
For 3-phase protected objects
1)
For busbar 1-phase
Voltage
3-phase
Voltage
1-phase
Current
3-phase
1)
Current (auxiliary) Current
1-phase
Current (auxiliary)
1-phase sensitive
2)
1-phase sensitive
2)
7UT613 3 3 1 9 3 1 1 1
7UT633 3 3 1 9 3 1 1 1
7UT635
51 1 —— — ——
44 2 124 2 ——
