Siemens SIPROTEC 7UT63 series - 3.1.3.2 Rack and Cubicle Mounting

3 Mounting and Commissioning
370
7UT613/63x Manual
C53000-G1176-C160-2
Figure 3-16 Panel flush mounting of a 7UT613 (housing size
1
/
2
) — example
Figure 3-17 Panel flush mounting of a 7UT633 or 7UT635 (housing size
1
/
1
) — example
3.1.3.2 Rack and Cubicle Mounting
Depending on the version, the device housing can be
1
/
2
or
1
/
1
. For housing size
1
/
2
(7UT613), there are 4 covers and 4 holes. For housing size
1
/
1
(7UT633 or 7UT635),
there are 6 covers and 6 holes.
