2.16 Frequency Protection
267
7UT613/63x Manual
C53000-G1176-C160-2
2.16.4 Information List
5644 T f> 0.00 .. 100.00 sec; ∞ 10.00 sec Delay time T f>
5651 Umin 10.0 .. 125.0 V; 0 65.0 V Minimum Required Voltage for
Operation
5652 U MIN 0.10 .. 1.25 U/UnS; 0 0.65 U/UnS Minimum voltage
No. Information Type of In-
formation
Comments
5203 >BLOCK Freq. SP >BLOCK frequency protection
5211 Freq. OFF OUT Frequency protection is switched OFF
5212 Freq. BLOCKED OUT Frequency protection is BLOCKED
5213 Freq. ACTIVE OUT Frequency protection is ACTIVE
5214 Freq UnderV Blk OUT Frequency protection undervoltage Blk
5254 Freq. error VT OUT Frequency protection: error VT assign.
5255 Freq. err. Obj. OUT Frequency prot.:Not avail. for this obj.
12006 >Freq. f< blk SP >Frequency prot.: Block Stage f<
12007 >Freq. f<< blk SP >Frequency prot.: Block Stage f<<
12008 >Freq. f<<< blk SP >Frequency prot.: Block Stage f<<<
12009 >Freq. f> blk SP >Frequency prot.: Block Stage f>
12032 Freq. f< P-up OUT Frequency prot.: Pick-up Stage f<
12033 Freq. f<< P-up OUT Frequency prot.: Pick-up Stage f<<
12034 Freq. f<<< P-up OUT Frequency prot.: Pick-up Stage f<<<
12035 Freq. f> P-up OUT Frequency prot.: Pick-up Stage f>
12036 Freq. f< TRIP OUT Frequency prot.: Trip Stage f<
12037 Freq. f<< TRIP OUT Frequency prot.: Trip Stage f<<
12038 Freq. f<<< TRIP OUT Frequency prot.: Trip Stage f<<<
12039 Freq. f> TRIP OUT Frequency prot.: Trip Stage f>
Addr. Parameter Setting Options Default Setting Comments
