2 Functions
324
7UT613/63x Manual
C53000-G1176-C160-2
2.22.7.4 Information List
0 Func. assigned I-CT 1
I-CT 2
I-CT 3
I-CT 4
I-CT 5
I-CT 6
I-CT 7
I-CT 8
I-CT 9
I-CT 10
I-CT 11
I-CT 12
I-CT 1 Function is applied to
0 Func. assigned AuxiliaryCT IX1
AuxiliaryCT IX2
AuxiliaryCT IX3
AuxiliaryCT IX4
AuxiliaryCT IX1 Function is applied to
0 Func. per phase UL1E..UL3E
UL1E
UL2E
UL3E
UL12..UL31
UL12
UL23
UL31
U0 (Zero seq.)
U1 (Pos. seq.)
U2 (Neg. seq.)
U4/Uen
UL1E..UL3E Function utilises component(s)
0 PICKUP WITH Exceeding
Dropping below
Exceeding Pickup with
0A Type of meas. accurate
fast
accurate Selection of type of measurement
No. Information Type of In-
formation
Comments
235.2110 >BLOCK $00 SP >BLOCK Function $00
235.2111 >$00 instant. SP >Function $00 instantaneous TRIP
235.2113 >$00 BLK.TDly SP >Function $00 BLOCK TRIP Time Delay
235.2114 >$00 BLK.TRIP SP >Function $00 BLOCK TRIP
235.2115 >$00 BL.TrpL1 SP >Function $00 BLOCK TRIP Phase L1
235.2116 >$00 BL.TrpL2 SP >Function $00 BLOCK TRIP Phase L2
235.2117 >$00 BL.TrpL3 SP >Function $00 BLOCK TRIP Phase L3
235.2118 $00 BLOCKED OUT Function $00 is BLOCKED
235.2119 $00 OFF OUT Function $00 is switched OFF
235.2120 $00 ACTIVE OUT Function $00 is ACTIVE
235.2121 $00 picked up OUT Function $00 picked up
235.2122 $00 pickup L1 OUT Function $00 Pickup Phase L1
235.2123 $00 pickup L2 OUT Function $00 Pickup Phase L2
235.2124 $00 pickup L3 OUT Function $00 Pickup Phase L3
Addr. Parameter C Setting Options Default Setting Comments
To Next Page
Loading...
