2.1 General
97
7UT613/63x Manual
C53000-G1176-C160-2
More details on how to navigate between the setting groups, to copy and reset setting
groups, and how to switch over between the setting groups during operation, can be
found in the SIPROTEC 4 System Description /1/.
The preconditions for switching from one setting group to another via binary inputs is
described in the Subsection „Mounting and Commissioning“.
2.1.5.2 Setting Notes
CHANGE Activates the setting group switching (address 302), only possible, if the setting group
switching feature in the function selection has been set to Enabled.
2.1.5.3 Settings
2.1.5.4 Information List
2.1.6 Power System Data 2
The general protection data (P.System Data 2) include settings associated with all
functions rather than a specific protection, monitoring or control function. In contrast
to the P.System Data 1 as discussed before, they can be changed over with the
setting groups and set on the operator panel of the device. Only a subset of the infor-
mation contained in the information list can appear, depending on the version and the
selected protected object.
2.1.6.1 Setting Notes
Sign of Power For all protective and additional functions, in which the polarity of the measured values
plays a role, the definition of signs is important. As a matter of principle, currents and
power are defined positive when flowing into the protected object. The consistency of
Addr. Parameter Setting Options Default Setting Comments
302 CHANGE Group A
Group B
Group C
Group D
Binary Input
Protocol
Group A Change to Another Setting Group
No. Information Type of In-
formation
Comments
- Group A IntSP Group A
- Group B IntSP Group B
- Group C IntSP Group C
- Group D IntSP Group D
7 >Set Group Bit0 SP >Setting Group Select Bit 0
8 >Set Group Bit1 SP >Setting Group Select Bit 1
