Siemens SIPROTEC 7UT63 series User Manual

2.1 General
95
7UT613/63x Manual
C53000-G1176-C160-2
711 EARTH IX1 AT Terminal Q7
Terminal Q8
Terminal Q7 Earthing electrod IX1 connected to
712 IN-PRI CT IX1 1 .. 100000 A 200 A CT rated primary current IX1
713 IN-SEC CT IX1 1A
5A
1A CT rated secondary current IX1
721 EARTH IX2 AT Terminal N7
Terminal N8
Terminal N7 Earthing electrod IX2 connected to
722 IN-PRI CT IX2 1 .. 100000 A 200 A CT rated primary current IX2
723 IN-SEC CT IX2 1A
5A
1A CT rated secondary current IX2
731 EARTH IX3 AT Terminal R7
Terminal R8
Terminal R7 Earthing electrod IX3 connected to
732 IN-PRI CT IX3 1 .. 100000 A 200 A CT rated primary current IX3
733 IN-SEC CT IX3 1A
5A
1A CT rated secondary current IX3
734 FACTOR CT IX3 1.0 .. 300.0 60.0 Factor: prim. over sek. current IX3
741 EARTH IX4 AT Terminal P7
Terminal P8
Terminal P7 Earthing electrod IX4 connected to
742 IN-PRI CT IX4 1 .. 100000 A 200 A CT rated primary current IX4
743 IN-SEC CT IX4 1A
5A
1A CT rated secondary current IX4
744 FACTOR CT IX4 1.0 .. 300.0 60.0 Factor: prim. over sek. current IX4
801 UN-PRI VT SET 1.0 .. 1200.0 kV 110.0 kV VT Rated Prim. Voltage Set UL1,
UL2, UL3
802 UN-SEC VT SET 80 .. 125 V 100 V VT Rated Sec. Voltage Set UL1,
UL2, UL3
803 CORRECT. U Ang -5.00 .. 5.00 ° 0.00 ° Angle correction UL1, UL2, UL3 -
VT
811 UN-PRI VT U4 1.0 .. 1200.0 kV 110.0 kV VT Rated Primary Voltage U4
812 UN-SEC VT U4 80 .. 125 V 100 V VT Rated Secondary Voltage U4
816 Uph / Udelta 0.10 .. 9.99 1.73 Matching ratio Phase-VT to Open-
Delta-VT
817 Uph(U4)/Udelta 0.10 .. 9.99 1.73 Matching ratio Ph-VT(U4) to Open-
DeltaVT
831 SwitchgCBaux S1 (Setting options depend
on configuration)
Q0 Switchgear / CBaux at Side 1
832 SwitchgCBaux S2 (Setting options depend
on configuration)
None Switchgear / CBaux at Side 2
833 SwitchgCBaux S3 (Setting options depend
on configuration)
None Switchgear / CBaux at Side 3
834 SwitchgCBaux S4 (Setting options depend
on configuration)
None Switchgear / CBaux at Side 4
835 SwitchgCBaux S5 (Setting options depend
on configuration)
None Switchgear / CBaux at Side 5
Addr. Parameter Setting Options Default Setting Comments
