Siemens SIPROTEC 7UT63 series User Manual

2 Functions
58
7UT613/63x Manual
C53000-G1176-C160-2
Address 224 ASSIGNM. 4M,3S appears if 4 assigned measuring locations (address
212) have been selected for 3 sides (address 213). The following options are possi-
ble:
• M1+M2,M3,M4, i.e. the 4 measuring locations are assigned: M1 and M2 to side S1,
M3 to side S2, M4 to side S3. This corresponds to the examples in Figures 2-3 and
2-5.
• M1,M2+M3,M4, i.e. the 4 measuring locations are assigned: M1 to side S1, M2 and
M3 to side S2, M4 to side S3.
• M1,M2,M3+M4, i.e. the 4 measuring locations are assigned: M1 to side S1, M2 to
side S2, M3 and M4 to side S3.
Address
225 ASSIGNM. 4M,4S appears if 4 assigned measuring locations (address
212) have been selected for 4 sides (address 213). Only one option is possible:
• M1,M2,M3,M4, i.e. the 4 measuring locations are assigned: M1 to side S1, M2 to
side S2, M3 to side S3, M4 to side S4.
Address
226 ASSIGNM. 5M,2S appears if 5 assigned measuring locations (address
212) have been selected for 2 sides (address 213). The following options are possi-
ble:
• M1+M2+M3,M4+M5, i.e. the 5 measuring locations are assigned: M1 and M2 and
M3 to side S1, M4 and M5 to side S2.
• M1+M2,M3+M4+M5, i.e. the 5 measuring locations are assigned: M1 and M2 to side
S1, M3 and M4 and M5 to side S2.
• M1+M2+M3+M4,M5, i.e. the 5 measuring locations are assigned: M1 and M2 and
M3 and M4 to side S1, M5 to side S2.
• M1,M2+M3+M4+M5, i.e. the 5 measuring locations are assigned: M1 to side S1, M2
and M3 and M4 and M5 to side S2.
Address
227 ASSIGNM. 5M,3S appears if 5 assigned measuring locations (address
212) have been selected for 3 sides (address 213). The following options are possi-
ble:
• M1+M2,M3+M4,M5, i.e. the 5 measuring locations are assigned: M1 and M2 to side
S1, M3 and M4 to side S2, M5 to side S3.
• M1+M2,M3,M4+M5, i.e. the 5 measuring locations are assigned: M1 and M2 to side
S1, M3 to side S2, M4 and M5 to side S3.
• M1,M2+M3,M4+M5, i.e. the 5 measuring locations are assigned: M1 to side S1, M2
and M3 to side S2, M4 and M5 to side S3.
• M1+M2+M3,M4,M5, i.e. the 5 measuring locations are assigned: M1 and M2 and
M3 to side S1, M4 to side S2, M5 to side S3.
• M1,M2+M3+M4,M5, i.e. the 5 measuring locations are assigned: M1 to side S1, M2
and M3 and M4 to side S2, M5 to side S3.
• M1,M2,M3+M4+M5, i.e. the 5 measuring locations are assigned: M1 to side S1, M2
to side S2, M3 and M4 and M5 to side S3.
Address
228 ASSIGNM. 5M,4S appears if 5 assigned measuring locations (address
212) have been selected for 4 sides (address 213). The following options are possi-
ble:
• M1+M2,M3,M4,M5, i.e. the 5 measuring locations are assigned: M1 and M2 to side
S1, M3 to side S2, M4 to side S3, M5 to side S4.
• M1,M2+M3,M4,M5, i.e. the 5 measuring locations are assigned: M1 to side S1, M2
and M3 to side S2, M4 to side S3, M5 to side S4.
