SIRIUS 3RT2 contactors/contactor assemblies
2.7 Accessories
SIRIUS Innovations
System Manual, 01/2011, A8E56203870002-03
197
2.7.13 Cover for ring cable lug
2.7.13.1 Description
For the version with a ring cable lug connection system the SIRIUS modular system features
attachable cover caps for ensuring touch protection (finger safety) according to IEC 61140.
Both line-side and output-side covers are available.
Table 2- 48 Versions of the cover for the ring cable lug
Size Order number
S00 3RT2916-4EA13
S0 3RT2926-4EB13
Figure 2-35 3RT2 power contactor with ring cable lug cover (size S0)
