SIRIUS 3RF34 solid-state switching devices
3.11 Technical data
SIRIUS Innovations
360 System Manual, 01/2011, A8E56203870002-03
3.11.12 Solid-state contactor - fused design with 3RB30 overload relay
Fused design with directly mounted 3RB30 overload relay
Table 3- 44 Main circuit
Order no. 3RF34 03-.BD.4 3RF34 05-.BD.4 3RF34 10-.BD.4
Rated operational current
I
AC-53
1)
acc. to IEC 60947-4-2
At 40 °C A 3.8 (3.4) 5.4 (4.8) 7.4
UL/CSA at 50 °C A 3.5 (3.1) 5 (4.3) 6.8
At 60 °C A 3.2 (2.8) 4.6 (3.8) 6.2
Power loss at
I
AC-53
at 40 °C W 7 (6) 9 (8) 13
Minimum load current A 0.5 0.5 0.5
Max. leakage current mA 10 10 10
Rated peak withstand current
I
tsm
A 600 600 600
I
2
t
value A
2
s 1800 1800 1800
1)
The reduced values in brackets apply in the case of a directly mounted motor starter protector combined with side-by-
side mounting.
2)
To reduce the risk of an inter-phase short circuit due to overvoltage, we recommend connecting a 3TX7 462-3L type
varistor between phases L1 and L3, as close as possible to the switching device. We recommend a design with
semiconductor protection to provide short-circuit protection.
3.11.13 Solid-state reversing contactor - main circuit, 2-phase controlled
Solid-state reversing contactor, 2-phase controlled
Table 3- 45 Main circuit
Order no. 3RF34..- BD.4
Controlled phases 2-phase
Rated operational voltage
Operating range
U
e
V 40 ... 506
Rated frequency Hz 50 / 60 ± 10 %
Rated insulation voltage
U
s
V 600
Rated impulse withstand voltage
U
imp
kV 6
Blocking voltage V 1200
Voltage gradient V/μs 1000
