SIRIUS 3RF34 solid-state switching devices
3.1 Safety instructions
SIRIUS Innovations
System Manual, 01/2011, A8E56203870002-03
315
3.1.1 Standards
Standards and approvals
● IEC 60947-4-2
● UL 508, CSA for North America
1)
● CE mark for Europe
● C-Tick approval for Australia
● CCC for China
1)
Please note: Use overvoltage protection device;
max. cut-off-voltage 6000 V;
min. energy handling capability 100J.
Applicable standards
The product meets the requirements of the following standards:
Table 3- 1 Applied standards (product)
Applications Standard
Device standard DIN IEC 60947-4-2
Terminal designations/Terminal markings DIN EN 50011
Degree of protection IP20 DIN IEC 0529
Vibration resistance DIN IEC 60068-2-6
Shock resistance DIN IEC 60068-2-27
EMC standard DIN IEC 60947-4-2; DIN IEC 61000-4-2;
DIN IEC 61000-4-6; DIN IEC 61000-4-4;
DIN IEC 61000-4-5
Resistance to extreme climates DIN IEC 60068-2-61 (sequence of tests),
DIN IEC 60068-2-30 (damp heat),
DIN IEC 60068-2-2 (dry heat),
DIN IEC 60068-2-1 (cold),
DIN IEC 60068-2-14 (temperature change)
Reference
The standards from Catalog LV 1 "Low-Voltage Controls and Distribution SIRIUS -
SENTRON - SIVACON" in the appendix always apply. You will find extracts from the most
important standards relating to the SIRIUS modular system in the chapter titled System
overview, underStandards (Page 23).
