SIRIUS 3RV2 motor starter protectors
4.9 Accessories
SIRIUS Innovations
System Manual, 01/2011, A8E56203870002-03
407
4.9 Accessories
4.9.1 Accessories overview
Accessories
For maximum flexibility, accessories can be added to the motor starter protector as required,
easily, and without the need for tools.
Mountable accessories
The mountable accessories for size S00/S0 3RV2 motor starter protectors are illustrated
below.
7
8
5
6
3
4
1
2
1 Signaling switch
2 Lateral auxiliary switch with 2 contacts
3 Lateral auxiliary switch with 4 contacts
4 Disconnector module
5 Terminal block type E
6 Undervoltage release
7 Shunt release
8 Transverse auxiliary switch
Figure 4-7 Motor starter protector size S00/S0 with mountable accessories
