SIRIUS 3RT2 contactors/contactor assemblies
2.8 Technical data
SIRIUS Innovations
System Manual, 01/2011, A8E56203870002-03
251
2.8.1.10 Rated data for auxiliary contacts (CSA and UL)
Table 2- 89 Rated data for auxiliary contacts (CSA and UL)
Screw connection and
spring-loaded
connection
Screw connection and
spring-loaded
connection
Screw connection and
spring-loaded
connection
Type
Integrated or snap-on
auxiliary switch block
Integrated or snap-on
auxiliary switch block
Laterally
mountable
auxiliary switch block
Size S00 S0 S00/S0
CSA and UL rated data for auxiliary
contacts
Rated voltage V AC 600 600 600
Switching capacity A 600, Q 600 A 600, Q 600 A 300, Q 600
Continuous
current at
240 V AC
A 10 10 10
