SIRIUS 3RV2 motor starter protectors
4.10 Technical data
SIRIUS Innovations
System Manual, 01/2011, A8E56203870002-03
467
4.10.11.3 Short-circuit breaking capacity for motor starter protectors with limiter function
Short-circuit breaking capacity for motor starter protectors with limiter function for 500 V AC and
690 V AC according to IEC 60947-2
The data for the short-circuit breaking capacity of motor starter protectors with limiter
function can be obtained on request on the Internet.
See also
Service & Support (http://www.siemens.com/automation/service&support)
4.10.12 Permissible rated data of approved devices for North America (UL/CSA)
4.10.12.1 Approved according to UL 508/CSA C22.2 No. 14
The motor starter protectors in the 3RV2 series are approved for UL/CSA and can be used
conforming to UL 508 and CSA C22.2 No.14 individually or as load feeders in conjunction
with a contactor.
These motor starter protectors can be used as "Manual Motor Controller" for "Group
Installations", as "Manual Motor Controller Suitable for Tap Conductor Protection in Group
Installations", and as "Self-Protected Combination Motor Controller (Type E)".
Horsepower data
Voltage
115 V 200/208 V 230/240 V 460/480 V 575/600 V
Operating
current
1-phase 3-phase 1-phase 3-phase 1-phase 3-phase 1-phase 3-phase 1-phase 3-phase
3RV2011/3RV2111/3RV2311/3RV2411 size S00
0.11...0.1
6
- - - - - - - - - -
0.14...0.2 - - - - - - - - - -
0.18...0.2
5
- - - - - - - - - -
0.22..0.32 - - - - - - - - - -
0.28...0.4 - - - - - - - - - -
0.35...0.5 - - - - - - - - - -
0.45...0.6
3
- - - - - - - - - -
0.55...0.8 - - - - - - - - - -
0.7...1 - - - - - - - - - 1/2
0.9...1.25 - - - - - - - 1/2 - 1/2
1.1...1.6 - - - - 1/10 - - 3/4 - 3/4
