SIRIUS 3RF34 solid-state switching devices
3.12 Dimension drawings (dimensions in mm)
SIRIUS Innovations
System Manual, 01/2011, A8E56203870002-03
373
3.12.2 Link module for motor starter protector
Accessories
Link module 3RA2921-1BA00 for 3RV20 motor starter protector
20.7
43.1
72.9
14.414.4
44.8
Figure 3-30 Link module for motor starter protector
