SIRIUS 3RF34 solid-state switching devices
3.11 Technical data
SIRIUS Innovations
System Manual, 01/2011, A8E56203870002-03
359
3.11.10 Solid-state reversing contactor with integration of four current paths to form a
single reversing circuit
Solid-state reversing contactor - instantaneous switching - 2-phase controlled - screw connection
Table 3- 41 Rated operational voltage
U
e
48 to 480 V
Order no. 3RF34 03-1BD04 3RF34 05-1BD04 3RF34 10-1BD04
Rated operational current
I
e
A 3.8 5.4 7.4
Rated power at
I
e
and
U
e
400 V kW 1.5 2.2 3.0
Rated control supply voltage
U
s
V DC 24 acc to. EN 61131-2
Weight per PU approx. kg 0.280 0.280 0.410
Table 3- 42 Rated operational voltage
U
e
48 to 480 V
Order no. 3RF34 03-1BD24 3RF34 05-1BD24 3RF34 10-1BD24
Rated operational current
I
e
A 3.8 5.4 7.4
Rated power at
I
e
and
U
e
400 V kW 1.5 2.2 3.0
Rated control supply voltage
U
s
V AC 110 to 230
Weight per PU approx. kg 0.280 0.280 0.410
3.11.11 Solid-state contactors - fuseless design with CLASS 10 motor starter protector
Fuseless design with CLASS 10 motor starter protector
Table 3- 43 Main circuit
Order no. 3RF34 03-.BD.4 3RF34 05-.BD.4 3RF34 10-.BD.4
Rated operational current
I
AC-53
1)
acc. to IEC 60947-4-2
at 40 °C A 3.8 (3.4) 5.4 (4.8) 7.4
UL/CSA at 50 °C A 3.5 (3.1) 5 (4.3) 6.8
at 60 °C A 3.2 (2.8) 4.6 (3.8) 6.2
Power loss at
I
AC-53
at 40 °C W 7 (6) 9 (8) 13
Short-circuit protection with type of coordination "1" at operational voltage
U
e
up to 440 V
Motor starter protector Type 3RV20 11-1FA10 3RV20 11-1GA10 3RV20 11-1JA10
I
q
kA 50 50 10
1)
The reduced values in brackets apply in the case of a directly mounted motor starter protector combined with side-by-
side mounting.
2)
To reduce the risk of an inter-phase short circuit due to overvoltage, we recommend connecting a 3TX7 462-3L type
varistor between phases L1 and L3, as close as possible to the switching device. We recommend a design with
semiconductor protection to provide short-circuit protection.
