SIRIUS 3RR2 current monitoring relays
8.10 Technical data
SIRIUS Innovations
740 System Manual, 01/2011, A8E56203870002-03
8.10.2.2 Main circuit
Table 8- 19 Technical data for the main circuit, 3RR21 current monitoring relay
Type 3RR2141 3RR2142
Size S00 S0
Width 45 mm 45 mm
Rated insulation voltage U
i
(pollution degree 3)
V 690
Rated impulse withstand voltage U
imp
kV 6
Rated operational voltage U
e
V 690
Relative measuring accuracy % 10
Current carrying capacity
for permanent overcurrent
A max. 16 max. 40
for overcurrent < 1 s
A max. 320 max. 800
Type of current
Alternating current
Hz 50 / 60
Current setting A 1.6 ... 16 4 to 40 A
Power loss per device (max.) W 2.5
Short-circuit protection
With fuse without contactor
See "Selection and ordering data" in Catalog
LV 1 N SIRIUS Innovations
With fuse and contactor
See the chapter titled "Motor starter protectors (Page 379)"
