SIRIUS 3RT2 contactors/contactor assemblies

2.7 Accessories

SIRIUS Innovations

224 System Manual, 01/2011, A8E56203870002-03

Step Operating instruction Figure

5 Push the locking slide

down with a screwdriver

until it engages.



6 / 7 Insert the coded module

connector into the slot in

the correct position from

above until the module

connector engages in the

locking mechanism.





Note

The function modules are mounted on the contactor assemblies for star-delta (wye-delta)

start described below as previously described.
