SIRIUS 3RT2 contactors/contactor assemblies
2.8 Technical data
SIRIUS Innovations
System Manual, 01/2011, A8E56203870002-03
237
Type 3RT2015 3RT2016 3RT2017 3RT2018
Size S00
Main circuit - Current carrying capacity for alternating current
Utilization category AC-4 (at I
a
= 6 x I
e
)
3)
 Rated operational current I
e
Up to 400 V A 6.5 8.5 8.5 11.5
 Rated powers of squirrel-cage
motors at 50 and 60 Hz
Up to 400 V kW 3 4 4 5.5
 The following applies for a contact service life of approximately
200,000 operating cycles:
Up to 400 V A 2.6 4.1 4.1 5.5 - Rated operational
currents I
e
690 V A 1.8 3.3 3.3 4.4
At 230 V kW 0.67 1.1 1.1 1.5
400 V kW 1.15 2 2 2.5
500 V kW 1.45 2 2 3
- Rated powers of
squirrel-cage motors
at 50 Hz and 60 Hz
690 V kW 1.15 2.5 2.5 3.5
Utilization category AC-5a, switching of gas discharge lamps,
inductive ballast
Per main current path at 230 V
 Uncorrected, rated power per lamp/rated operational current
per lamp
L 18 W/0.37 A Qty. 47 52
L 36 W/0.43 A Qty. 40 48
L 58 W/0.67 A Qty. 26 28
L 80 W/0.79 A Qty. 22 24
 DUO switching (two-lamp)
L 18 W/0.22 A Qty. 90
(≙ 2 x 90
lamps)
100
(≙ 2 x 100 lamps)
L 36 W/0.42 A Qty. 47
(≙ 2 x 47
lamps)
52
(≙ 2 x 52 lamps)
L 58 W/0.63 A Qty. 31
(≙ 2 x 31
lamps)
34
(≙ 2 x 34 lamps)
L 80 W/0.87 A Qty. 22
(≙ 2 x 22
lamps)
25
(≙ 2 x 25 lamps)
