SIRIUS 3RT2 contactors/contactor assemblies
2.8 Technical data
SIRIUS Innovations
System Manual, 01/2011, A8E56203870002-03
239
Type 3RT2015 3RT2016 3RT2017 3RT2018
Size S00
Main circuit - Current carrying capacity for alternating current
Utilization category AC-6a, switching AC transformers
ï‚· Rated operational current I
e
- For inrush current
n = 20
Up to 400 V A 4 5.3 7.2 9.6
- For inrush current
n = 30
Up to 400 V A 2.7 3.5 4.8 6.4
ï‚· Rated power P
At 230 V kVA 1.4 2 2.9 3.8
400 V kVA 2.5 3.5 5 6.6
500 V kVA 3.3 4.6 6.2 8.3
- For inrush current
n = 20
690 V kVA 4.3 6 8.6 11.4
At 230 V kVA 1 1.3 2 2.5
400 V kVA 1.6 2.3 3.5 4.4
500 V kVA 2.2 3.1 4.6 5.5
- For inrush current
n = 30
690 V kVA 2.9 4 6 7.6
For deviating inrush current factors x, the power must be recalculated as follows: P
x
= P
n
30 · 30/x
1)
The OFF-delay times of the NO contacts and the ON-delay times of the NC contacts increase if the contactor coils are
attenuated against voltage peaks (suppression diode 6x to 10x; diode combinations 2x to 6x; varistor +2 to 5 ms).
2)
Acc. to IEC 60947-4-1. See the chapter titled "Overload relays" for rated values for different starting conditions.
3)
The data specified is valid for 3RT2516 and 3RT2517 (2 NO contacts + 2 NC contacts) only up to a rated operational
current of 400 V.
4)
The number of lamps can be increased dependent upon the electronic ballast used.
