SIRIUS 3RT2 contactors/contactor assemblies
2.8 Technical data
SIRIUS Innovations
System Manual, 01/2011, A8E56203870002-03
249
Type 3RT20
23
3RT20
24
3RT20
25
3RT20
26
3RT20
27
3RT20
28
Size S0
Main circuit - Current carrying capacity for alternating current
Utilization category AC-5a, switching of gas discharge lamps,
inductive ballast
Per main current path at 230 V
3)
ï‚· Rated power per lamp/rated operational current per lamp
L 18 W/0.37 A Qty. 95 118
L 36 W/0.43 A Qty. 81 102
L 58 W/0.67 A Qty. 52 65
- Uncorrected
L 80 W/0.79 A Qty. 44 55
L 18 W/0.22 A Qty. 181 (≙ 2 x 181 lamps) 227 (≙ 2 x 227
lamps)
L 36 W/0.42 A Qty. 95 (≙ 2 x 95 lamps) 119 (≙ 2 x 119
lamps)
L 58 W/0.63 A Qty. 63 (≙ 2 x 63 lamps) 79 (≙ 2 x 79
lamps)
- DUO switching (two-lamp)
L 80 W/0.87 A Qty. 45 (≙ 2 x 45 lamps) 57 (≙ 2 x 57
lamps)
Switching of gas discharge lamps with correction
Per main current path at 230 V
ï‚· Rated power per lamp/capacitance/rated operational current
per lamp
L 18 W/4.5 μF/0.11 A Qty. 37 41 61 78 93
L 36 W/4.5 μF/0.21 A Qty. 30 30 51 71 71
L 58 W/7.0 μF/0.32 A Qty. 20 20 33 46 46
- Shunt compensation,
with inductive ballast
L 80 W/7.0 μF/0.49 A Qty. 13 13 22 30 30
L 18 W/6.8 μF/0.10 A Qty. 105 119 175 224 266
L 36 W/6.8 μF/0.18 A Qty. 58 66 97 124 147
L 58 W/10 μF/0.29 A Qty. 36 41 60 77 91
- With solid-state
ballast
4)
single-lamp
L 80 W/10 μF/0.43 A Qty. 24 27 40 52 61
L 18 W/10 μF/0.18 A Qty. 58 (≙
2 x 58 lamps)
66 (≙
2 x 66
lamps)
97 (≙
2 x 97
lamps)
124 (≙
2 x 12
4 lamp
s)
147 (≙
2 x 147
lamps)
L 36 W/10 μF/0.35 A Qty. 30 (≙
2 x 30 lamps)
34 (≙
2 x 34
lamps)
50 (≙
2 x 50
lamps)
64 (≙
2 x 64
lamps)
76 (≙
2 x 76
lamps)
L 58 W/22 μF/0.52 A Qty. 20 (≙
2 x 20 lamps)
22 (≙
2 x 22
lamps)
33 (≙
2 x 33
lamps)
43 (≙
2 x 43
lamps)
51 (≙
2 x 51
lamps)
- With solid-state
ballast
4)
two-lamp
L 80 W/22 μF/0.86 A Qty. 12 (≙
2 x 12 lamps)
13 (≙
2 x 13
lamps)
20 (≙
2 x 20
lamps)
26 (≙
2 x 26
lamps)
30 (≙
2 x 30
lamps)
