SIRIUS 3RT2 contactors/contactor assemblies
2.8 Technical data
SIRIUS Innovations
System Manual, 01/2011, A8E56203870002-03
259
Table 2- 96 Actuation of 3RT231. and 3RT232. contactors
Type 3RT2316 3RT2317 3RT2325 3RT2326 3RT2327
Size S00 S0
Actuation
Magnet coil operating range AC/DC --- 0.8 to 1.1 x U
S
 AC operation
50 Hz 0.8 to 1.1 x U
S
---
60 Hz 0.85 to 1.1 x U
S
---
 DC operation
Up to 50 °C 0.8 to 1.1 x U
S
---
Up to 60 °C 0.85 to 1.1 x U
S
---
Magnet coil power input (for cold coil and 1.0 x U
S
)
 AC operation, 50 Hz, standard version
- Switch-on power VA --- 77
- cos ϕ --- 0.82
- Holding power VA --- 9.8
- cos ϕ --- 0.25
 AC operation, 50/60 Hz, standard version
- Switch-on power VA 27/24.3 37/33 81/79
- cos ϕ 0.8/0.75 0.8/0.75 0.72/0.74
- Holding power VA 4.2/3.3 5.7/4.4 10.5/8.5
- cos ϕ 0.25/0.25 0.25/0.25 0.25/0.28
 AC operation, 50 Hz, USA/Canada
- Switch-on power VA 26.4 36 77
- cos ϕ 0.81 0.8 0.82
- Holding power VA 4.4 5.9 9.8
- cos ϕ 0.24 0.24 0.25
 AC operation, 60 Hz, USA/Canada
- Switch-on power VA 31.7 43 87
- cos ϕ 0.77 0.77 0.76
- Holding power VA 4.8 6.5 9.4
- cos ϕ 0.25 0.25 0.28
 DC operation
- Switch-on power =
holding power
W 4 5.9
