SIRIUS 3RT2 contactors/contactor assemblies
2.8 Technical data
SIRIUS Innovations
262 System Manual, 01/2011, A8E56203870002-03
Type 3RT2316 3RT2317 3RT2325 3RT2326 3RT2327
Size S00 S0
Main circuit - Current carrying capacity for direct current
Up to 24 V A 16 20 30 35 42
60 V A 16 20 30 35 42
110 V A 16 20 30 35 42
220 V A 16 20 30 35 42
- 3 current
paths in
series
440 V A 1.3 2.9
Up to 24 V A 16 20 30 35 42
60 V A 16 20 30 35 42
110 V A 16 20 30 35 42
220 V A 16 20 30 35 42
- 4 current
paths in
series
440 V A 1.3 2.9
Utilization category DC-3/DC-5, shunt-wound and series-wound motors (L/R ≤ 15 ms)
 Rated operational currents I
e
(at 60 °C)
Up to 24 V A 16 20
60 V A 0.5 5
110 V A 0.15 2.5
220 V A --- --- 1
- 1 current
path
440 V A --- --- 0.09
Up to 24 V A 16 20 30 35 42
60 V A 5 30 35 42
110 V A 0.35 15
220 V A --- --- 3
- 2 current
paths in
series
440 V A --- --- 0.27
Up to 24 V A 16 20 30 35 42
60 V A 16 20 30 35 42
110 V A 16 20 30 35 42
220 V A 1.5 10
- 3 current
paths in
series
440 V A 0.2 0.6
Up to 24 V A 16 20 30 35 42
60 V A 16 20 30 35 42
110 V A 16 20 30 35 42
220 V A 1.5 30 35 42
- 4 current
paths in
series
440 V A 0.2 0.6
